Disco DFD650

Disco DFD650

Contact us for price

orCall +353 (0) 87 192 1110

Description

Facility: (1) Electric Power Input: Within AC200V±10% 3? 50/60Hz Electric consumption: 4kVA (Max) (2) CDA Pressure: 0.49MPa?G (5.0kgf/cm2?G) Flow: 350NL/min? (3) N2 Pressure: 0.49MPa?G (5.0kgf/cm2?G) Flow: 200NL/min? (4) Pure Water Pressure(Dicer): 0.29MPa (3.0kgf/cm2?G) Pressure(Spinner): 0.29MPa (3.0kgf/cm2?G) Flow(Dicer): 13L/min? Flow(Spinner): 13L/min? (5) Cooling Water Pressure: 0.20MPa (2.0kgf/cm 2) Flow: 3.0L/min? (6) Drain Connection: Duct hose ?50mm (7) Exhaust Exhaust value: ?5m3/min Connection: Duct hose ?100mm (8) Main size W:D:H = 1350mm:1168mm:1235mm (without monitor & protuberance) (9) Weight: 1300kg

Specifications

ManufacturerDisco
ModelDFD650
Year1997
ConditionUsed
Stock Number27072015.0
