Alcatel A803H

Alcatel A803H

Configuration: Audit to verify.

Pump has not been refurbished and is not skidded or crated.

Technical Specifications：

Peak pumping speed 50Hz : 10000 l/min

Peak pumping speed 60Hz : 11667 l/min

Ultimate pressure Max (No Purge) 50Hz : 1.5x10-3 torr

Ultimate pressure Max (No Purge) 60Hz : 6.7x10-4 torr

Ultimate pressure Max (50 SLM Purge) 50Hz : 6.7x10-3 torr

Ultimate pressure Max (50 SLM Purge) 60Hz : 4.5x10-3 torr

Motor rating : 4.3 kw

Max continue inlet flow : 100 SLM

N2 purge flow : NA

Cooling water : 1.3 l/min

Inlet connection : DN100

Outlet connection : DN40

Dimensions : L834 x W390 x H883 mm

Max sound level : < 68 dBA
