JUKI KD-2077 High speed inline glue dispenser SMA surface mount adhesive dispens

JUKI KD-2077 High speed inline glue dispenser SMA surface mount adhesive dispens

Contact us for price

orCall +353 (0) 87 192 1110

Description

JUKI KD-2077 High speed inline glue dispenser SMA surface mount adhesive dispens

JUKI KD-2077 High speed inline glue dispenser SMA surface mount adhesive dispenser


2010 Vintage, Windows XP O/S


220V 3 PH 30A


PWB dimensions(LxW)


Max


410×360mm


Min


50×30mm


Dispensing tact time


0.1 sec/dot (optimum condition)


Dispensing accuracy


±0.15mm


Syringe type


30cc


Preset dispensing angle


0°~359°(by 1°increment)


Three standard dispensing heads for high-speed dispensing production Comprehensive lineup of standard equipment provided to achieve stable continuous dispensing Automatic syringe pressure compensation / Dot size confirmation / Low adhesive warning / Independent temperature control for each head Up to 4 adhesive dots per dispense cycle Supports a wide range of components, from 1608 chips to aluminum electrolytic capacitors, SOPs, and QFPs.


Bad mark” detection for panelized boards Windows XP and graphical interface is familiar and easy to use Standard Ethernet port for network connection. Dual language displays allow switching between Japanese/English or English/Chinese. Compact design matches JUKI’s latest mounters

Specifications

ManufacturerJUKI
ModelKD-2077 High speed inline glue dispenser SMA surface mount adhesive dispens
ConditionUsed
Stock NumberEM1588
